Vinyl Tubing, 6 AWG (4.52mm), 300V Clear
| Material | Polyvinyl Chloride |
|---|---|
| Color | Clear |
| Application | 1) Provides Insulation and Protection for Lead Wires, Wire Harness Assemblies, Soldered Joints and Components in Electrical and Electronic Equipment, 2) All Purpose Flexible and Non-Shrinkable |
| Nominal Diameter (In.) | 0.178 |
| Overall Length (m) | 304.8 |
| Wall Thickness (mm) | 0.5 |
| Maximum Voltage (V) | 300 |
| Resistance Properties | Oil-Resistant |
| Inside Diameter (mm) | 4.5 |
| Nominal Diameter (mm) | 4.5 |
| Product Type | Tubing |
| Wall Thickness (In.) | 0.02 |
| Minimum Operating Temperature (°C) | -20 |
| Nominal Diameter (AWG) | 6 |
| Maximum Operating Temperature (°C) | 105 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Operating Temperature (°F) | 221 |
| Inside Diameter (In.) | 0.18 |
| Overall Length (ft.) | 1,000 |
| Max Operating Temperature | 105 degrees celsius |
| Min Operating Temperature | -20 degrees celsius |
| Product Class | Wire Routing, Management & Protection |
| Package Quantity | 1 |
