Normally Open Thru Ports 1 & 2, Aluminum, Buna-N Seal
| Valve Type | Internally-Piloted |
|---|---|
| Valve Way & Position | 4-Way/2-Position |
| Valve Configuration | In-Line |
| Port Size | 3/8 in |
| Valve Unactuated State | Normally Open Thru Ports 1 & 2 |
| Thread Standard | NPT |
| Body Material | Aluminum |
| Seal Material | Nitrile |
| Maximum Working Pressure (PSI - 3 Decimals) | 145.000 |
| Cv Factor Nc | 1.4000 |
| Overall Height (Decimal Inch) | 2.4100 |
| Overall Length (Decimal Inch) | 5.7800 |
| Standards | CE Marked |
| Inlet Size | 3/8 in |
| Cv Rating | 1.400 |
| Minimum Working Pressure (psi) | 20 |
| Special Item Information | Valve Less Coil; Flush - Locking Override Function |
| Applications | Pneumatics |
| Width (Decimal Inch - 4 Decimals) | 1.1800 |
| Maximum Temperature (F) ( - 0 Decimals) | 120 |
| Type Of Power | Single Acting |
| Minimum Temperature (Deg F - 3 Decimals) | 5 |
| Type | IP 65 |
| Maximum Temperature (C) | 49 |
| Minimum Temperature (C - 2 Decimals) | -15 |
| UNSPSC Code | 40141605 |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 91209270 |
