Collet Chuck, CAT50,100PG, Proj 7.500 In
| Item | Collet Chuck |
|---|---|
| Shank Type | Taper |
| Taper Size | CAT50 |
| Collet Series | PG100 |
| Projection | 7-1/2 in |
| Nut Dia. | 2.44 in |
| Material | Steel |
| Nose Dia. | 2.44 in |
| ANSI Number | C50-10SC7 |
| Bore Depth | 5-1/2 in |
| Coolant Fed | Coolant Through |
| ANSI Code | C50-10SC7 |
| Features | Durable Service Life;Hardened to 52 to 56 HRC to Avoid Damaging Collet Chuck Threads |
| Finish | Black Oxide |
| Product Type | CAT Collet Chuck |
| Number of Coolant Ports | 0 |
| Coolant Supply | Non-Coolant Through |
| Compatible Collet Series | PG100 |
| Includes Nut | Nut Included |
| Shank Diameter | 1 in |
| Torque - Maximum | 60 ft-lb |
| Standards | AISI 8620 |
| T.I.R. Tolerance | 0 in |
| Nut Diameter | 2.44 in |
| Package Quantity | 1 |
