Piano Hinge, Bronze, 83 in Leaf Ht, 1 3/8 in Leaf W
| Item | Piano Hinge |
|---|---|
| Material | Bronze |
| Load Capacity | 600 lb |
| Range of Motion | 180 deg |
| Holes per Leaf | 4 |
| Frame Leaf Width | 1-1/4 in |
| Holes | 12 |
| Door Leaf Width | 1-3/8 in |
| Door Leaf Height | 83 in |
| Door Leaf Thickness | 0.187 in |
| Overall Knuckle Height | Not Applicable |
| Orientation | Non Handed |
| Required Door Thickness | 1-3/4 in |
| ANSI/BHMA Finish | Clear Anodized, Satin Aluminum |
| Standards | BHMA Certified, cULus UL 76Y2, UL 10C |
| Range of Motion - Maximum | 180 deg |
| UL Fire Rating | UL10C |
| Hand Orientation | Non-Handed |
| Door Thickness - Maximum | 1 3/4 in |
| Mounting Style | Full Surface |
| Hinge Length | 2.88 in |
| Number of Holes per Leaf | 4 |
| Green Certification or Other Recognition | UL Environment Claims Validated |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
