Piano Hinge, Bronze, Full Mortise Mounting, 1 3/4 in Leaf W x 83 in Leaf H, Clear Anodized
| Item | Piano Hinge |
|---|---|
| Material | Bronze |
| Mounting | Full Mortise |
| Load Capacity | 540 lb |
| Range of Motion | 180 deg |
| Ligature Resistant | Yes |
| Holes per Leaf | 16 |
| Finish | Clear Anodized |
| Holes | With |
| Door Leaf Width | 1-3/4 in |
| Door Leaf Height | 83 in |
| Door Leaf Thickness | 0.187 in |
| Frame Leaf Width | 1-3/4 in |
| Frame Leaf Height | 83 in |
| Frame Leaf Thickness | 0.187 in |
| Orientation | Right Hand |
| Standards | ANSI/BHMA A156.26, UL Certified |
| Features | Hospital Tip; Standard Duty |
| Hardware | Not included |
| Length | 83 in |
| Overall Knuckle Height | 1 in |
| Hole Spacing | Varies |
| Overall Width | 2-5/8 in |
| Required Door Thickness | 1-3/4 in |
| UL Fire Rating | UL10C |
| Width | 25/32 in |
| Color | Silver |
| Hand Orientation | Non-Handed |
| Green Certification or Other Recognition | Environmental Transparency Through EPD (Environmental Product Declaration) |
| Door Thickness - Maximum | 1 3/4 in |
| Hinge Length | 10 ft |
| Door Thickness - Minimum | 1-3/4 in |
| Number of Holes per Leaf | 16 |
| Range of Motion - Maximum | 180 deg |
| Includes Hardware | Hardware Included |
| ANSI/BHMA Finish | Clear Anodized, Satin Aluminum |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
