Conector multitap aislado, 6.67 pulgadas de longitud.
| Item | Insulated Multitap Connector |
|---|---|
| Connector Type | Double-Sided Entry |
| No. of Ports | 6 |
| Min. Conductor Size | 6 AWG |
| Max. Conductor Size | 350 kcmil |
| Stud Size | 5/16 in |
| Insulation Material | Plastisol |
| Length | 6.6 in |
| Width | 2.41 in |
| Direct Burial Rated | No |
| Standards | cULus, UL 486A |
| Head Style | Hex |
| Max. Voltage | 600V AC/DC |
| Body Material | Aluminum |
| Screw Material | Aluminum |
| Length (Straight Wireway) | 6.6 in |
| For Conductor Material | Copper, Aluminum |
| Maximum Voltage | 600 V |
| Number of Ports | 6 |
| RoHS Compliant | Yes |
| Hex Size | 5/16 in |
| Maximum Operating Temperature | 194 deg F |
| Overall Width | 2.41 in |
| Tap Shape | Z |
| For Stranded Copper Wire Size - Minimum | 6 AWG |
| For Stranded Copper Wire Size - Maximum | 350 kcmil |
| Special Features | Abrasion and Chemical Resistant, Eliminates the Need for Cover and Taping, Insulated With High-Dielectric Strength Plastisol, Molded for Precise Fit and Supplied With Removable Access Plugs Over the Hex Screws, Supplied With Removable Plugs to Close the Entry Port Not Being Utilized, UV Resistant, Will Not Support Combustion, Wire Entry Ports on Both Sides of the Connector Allow for Access From Either Side |
| Torque | 400 in-lb |
| Overall Length | 6.67 in |
| Strip Length | 1-1/2 in |
| Minimum Operating Temperature | -49 deg F |
| Finish | Plastisol |
| Compatible with Product Type | Copper and Aluminum Cables |
| Color | Black |
| Conductor Cu Size Range | 350 MCM – 10 AWG |
| Cu Conductor Max Amp | 985 |
| Temp Rating | 90C, AL9CU |
| Conductors Count | 6 |
| Certifications | cULus |
| Max Torque | 400 |
| Al Conductor Max Amp | 770 |
| Conductor Al Size Range | 350 MCM – 10 AWG |
| Env Temp | Cold Temperature rated to -45C |
| Ul Standard | B, UL 486A |
| Assortment | Black UV Coated Pre-Insulated Connectors |
| Conductor Type | Copper, Aluminum |
| Ul File No | E186991 |
| Wire Cable Class | Class B, Class C |
| Hex Wrench Size | 0.3125 |
| Package Quantity | 1 |
