Relé, 110V de CC / 240V de CA Voltios de Bobina, 2 Formas C (CO)
| Item | Relay |
|---|---|
| Coil Volts | 110V DC/240V AC |
| Contact Form - Relay | 2 Form C (CO) |
| Mounting - Relay | Socket |
| Power Consumption - Relay | 1,200 mW |
| Contact Material | AgCdO |
| Body Height - Relay | 2 in |
| Body Width - Relay | 1.405 in |
| Body Depth - Relay | 1.406 in |
| Features | Monostable, DC Magnetic System; UL Coil Insulation Class B |
| Operating Temp. Range | 50 to 70 deg C |
| Coil Resistance | 10,000 ohms |
| Protection Category | RT I |
| Dielectric Strength | 1000 Vrms Between Adjacent Contacts; 500 to 1000 V Between Coil/Contact Class; 1000 Vrms Between Open Contacts |
| Package Quantity | 1 |
