PANEL MNT SSR SRS 25A 480V AC - DC I/P
Montaje en panel, SSR SRS 25A 480V AC - DC I/P
| Input Voltage Typical (VDC) | 4 to 32 |
|---|---|
| Product Type | Relay |
| Contact Current Rating (A) | 25 |
| Output Switching | Zero |
| Insulation Initial Dielectric Between Contacts and Coil (Vrms) | 4,000 |
| Relay Type | Paired SCR Output |
| Housing Style | Hockey Puck |
| Output Current (Min) (A) | 0.05 |
| Termination Type | Screws |
| Input Voltage (VDC) | 4 to 32 |
| Dimensions (L x W x H) (Approximate) | 44.4 x 57.2 x 22 mm [ 1.749 x 2.253 x .866 in ] |
| Mounting Type | Chassis Mount |
| Output Current Rating (Arms) | 0.05 to 25 |
| R-Switch & slimSSR Relays | No |
| Contact Arrangement | 1 Form A (SPST-NO) |
| Switch Arrangement | 1 Form A (SPST-NO) |
| Output Type | AC |
| Coupling | Optical |
| Operating Temperature Range (°C) | -20 to 80 |
| Output Voltage (Max) (V) | 660 |
| Output Voltage Rating (AC Relays) | 48 to 660 |
| Package Quantity | 1 |
