SSRD SRS PANEL MNT 25A 240V AC - DC I/P
Montaje en panel SSRD SRS 25A 240V AC - DC I/P
| Input Voltage Typical (VDC) | 4 to 15 |
|---|---|
| Switch Arrangement | (2) x 1 Form A (SPST-NO) |
| R-Switch & slimSSR Relays | No |
| Contact Current Rating (A) | 25 |
| Output Voltage (Max) (V) | 280 |
| Input Voltage (VDC) | 4 to 15 |
| Coupling | Optical |
| Output Current Rating (Arms) | 0.1 to 25 |
| Output Voltage Rating (AC Relays) | 24 to 280 |
| Output Current (Min) (A) | 0.1 |
| Dimensions (L x W x H) (Approximate) | 44.4 x 57.2 x 32 mm [ 1.749 x 2.253 x 1.26 in ] |
| Insulation Initial Dielectric Between Contacts and Coil (Vrms) | 4,000 |
| Output Type | AC |
| Mounting Type | Chassis Mount |
| Product Type | Relay |
| Relay Type | Dual AC Output |
| Output Switching | Zero |
| Housing Style | Industry Standard |
| Contact Arrangement | (2) x 1 Form A (SPST-NO) |
| Operating Temperature Range (°C) | -40 to 80 |
| Termination Type | .25 x .032 Quick Connect Terminals |
| Package Quantity | 1 |
