Panel de montaje de SSR de 25A 240V AC-AC I/P.
| Output Voltage (Max) (V) | 280 |
|---|---|
| Product Type | Relay |
| Relay Type | Snubberless Triac Output |
| Termination Type | Screws |
| Input Voltage Typical (VAC) | 90 to 280 |
| R-Switch & slimSSR Relays | No |
| Contact Current Rating (A) | 25 |
| Mounting Type | Chassis Mount |
| Input Voltage (VAC) | 90 to 280 |
| Operating Temperature Range (°C) | -20 to 80 |
| Housing Style | Hockey Puck |
| Output Switching | Zero |
| Output Voltage Rating (AC Relays) | 24 to 280 |
| Switch Arrangement | 1 Form A (SPST-NO) |
| Contact Arrangement | 1 Form A (SPST-NO) |
| Dimensions (L x W x H) (Approximate) | 44.4 x 57.2 x 22 mm [ 1.749 x 2.253 x .866 in ] |
| Output Type | AC |
| Insulation Initial Dielectric Between Contacts and Coil (Vrms) | 4,000 |
| Output Current Rating (Arms) | 0.1 to 25 |
| Coupling | Optical |
| Output Current (Min) (A) | 0.1 |
| Package Quantity | 1 |
