T81N5D312-05 es un código de producto que no tiene traducción al español.
| Width | 10.9 mm [ .429 in ] |
|---|---|
| Length | 15.9 mm [ .625 in ] |
| Contact Material | Ruthenium |
| Height | 11.7 mm [ .461 in ] |
| Coil Power Rating (DC) (mW) | 140 |
| Contact Limiting Making Current (A) | 1 |
| Insulation Initial Dielectric Between Open Contacts (Vrms) | 500 |
| Actuating System | DC |
| Contact Arrangement | 1 Form C (CO) |
| Insulation Creepage Between Contact and Coil | 1.76 mm [ .069 in ] |
| Relay Style | Signal Relay |
| Product Type | Relay |
| Power Consumption (mW) | 450 |
| Contact Voltage Rating | 120 VAC [ 24 VDC ] |
| Isolation (HF Parameter) | -39dB @ 100MHz, -20.7dB @ 900MHz |
| Contact Plating Material | Gold |
| Contact Limiting Breaking Current (A) | 1 |
| Insulation Clearance Class | 0 to 2.5 mm |
| Operating Temperature Range (°C) | -30 to 60 |
| Coil Resistance (Ω) | 55 |
| Insulation Creepage Class | 1.5 to 3 mm |
| Insulation Special Features | 1500V Initial Surge Withstand Voltage between Contacts & Coil |
| Insulation Initial Resistance (MΩ) | 1,000,000 |
| Insertion Loss (HF Parameter) | -.27dB @ 900MHz, -.02dB @ 100MHz |
| Mounting Type | Printed Circuit Board |
| Height Class (Mechanical) | 11 to 12 mm |
| Contact Switching Voltage (Max) | 125 VAC [ 60 VDC ] |
| Insulation Clearance Between Contact and Coil | 1.5 mm [ .059 in ] |
| Contact Number of Poles | 1 |
| Contact Limiting Short-Time Current (A) | 1 |
| Contact Current Rating (A) | 0.4 |
| Performance Type | Standard |
| Environmental Ambient Temperature (Max) | 60 °C [ 140 °F ] |
| Insulation Initial Dielectric Between Contacts and Coil (Vrms) | 1,000 |
| Terminal Type | PCB-THT |
| Coil Power Rating Class | 400 to 500 mW |
| Environmental Category of Protection | RTIII |
| Contact Switching Load (Min) | 1 mA @ 1 V |
| Termination Type | Through Hole |
| Relay Type | PCB Relay |
| Insulation Initial Dielectric Between Coil/Contact Class | 500 to 1,000 V |
| Environmental Ambient Temperature Class | 50 to 70 deg C |
| Coil Magnetic System | Monostable, DC |
| Coil Type | DC Coil |
| Contact Limiting Continuous Current (A) | 2 |
| Contact Current Class | 0 to 2 A |
| Package Quantity | 1 |
