T9AS5D22-24 puede ser un código de producto o referencia específico en algún contexto. No tiene una traducción específica al español, ya que parece ser una combinación de números y letras utilizado como identificador único.
| Contact Material | AgCdO |
|---|---|
| Length | 32.5 mm [ 1.281 in ] |
| Width | 27.4 mm [ 1.079 in ] |
| Height | 27.9 mm [ 1.098 in ] |
| Contact Limiting Continuous Current (A) | 20 |
| Insulation Clearance Between Contact and Coil | 3.18 mm [ .125 in ] |
| Coil Voltage Rating (VDC) | 24 |
| Contact Switching Voltage (Max) (VAC) | 277 |
| Insulation Initial Dielectric Between Coil/Contact Class | 1500 V to 2500 VA |
| Insulation Initial Dielectric Between Contacts and Coil (Vrms) | 2,500 |
| Coil Special Features | UL Coil Insulation Class F |
| Insulation Clearance Class | 2.5 to 4 mm |
| Insulation Creepage Class | 5.5 to 8 mm |
| Contact Current Class | 10 to 20 A, Greater Than 16A |
| Coil Power Rating (DC) (mW) | 1,000 |
| Contact Limiting Breaking Current (A) | 20 |
| Coil Magnetic System | Monostable, DC |
| Environmental Ambient Temperature (Max) | 85 °C [ 185 °F ] |
| Insulation Special Features | 6000V Initial Surge Withstand Voltage between Contacts & Coil |
| Mounting Type | Printed Circuit Board |
| Environmental Ambient Temperature Class | 70 to 85 deg C |
| Contact Switching Load (Min) | 1,000 mA @ 5 V |
| Insulation Initial Resistance (MΩ) | 1,000 |
| Insulation Creepage Between Contact and Coil | 6.36 mm [ .25 in ] |
| Terminal Type | Quick Connect |
| Contact Limiting Making Current (A) | 20 |
| Contact Limiting Short-Time Current (A) | 20 |
| Coil Resistance (Ω) | 576 |
| Contact Arrangement | 1 Form C (CO) |
| Insulation Initial Dielectric Between Open Contacts (Vrms) | 1,500 |
| Contact Number of Poles | 1 |
| Contact Current Rating (A) | 20 |
| Product Type | Relay |
| Coil Power Rating Class | 800 to 1,000 mW |
| Relay Type | PCB Relay |
| Contact Voltage Rating (VAC) | 277 |
| Environmental Category of Protection | RTIII |
| Package Quantity | 1 |
