T9CP1A52-120 - No es necesario traducir este texto ya que parece ser una referencia o código de producto específico.
| Contact Material | AgCdO |
|---|---|
| Product Length | 1.98 in |
| Insulation Clearance Between Contact & Coil | 1/8 in |
| Contact Current Rating (Max) | 30 A |
| Product Height | 1.098 in |
| Insulation Special Features | 6000V Initial Surge Withstand Voltage between Contacts & Coil |
| Width Class (Mechanical) | 25 to 30 mm |
| Contact Arrangement | 1 Form A (NO) |
| Coil Magnetic System | Monostable, AC |
| Contact Limiting Short-Time Current | 30 A |
| Contact Switching Voltage (Max) | 277 VAC |
| Insulation Initial Dielectric Between Contacts & Coil | 2,500 Vrms |
| Contact Limiting Making Current | 30 A |
| Insulation Clearance Class | 2.5 to 4 mm |
| Power Relay Type | Standard |
| Terminal Type | Quick Connect |
| Environmental Ambient Temperature Class | -40 to 70 deg C |
| Height Class (Mechanical) | 20 to 35 mm |
| Contact Switching Load (Min) | 1,000 mA @ 5 V |
| Insulation Creepage Class | 5.5 to 8 mm |
| Contact Current Class | 20 to 30 A, 16 A |
| Length Class (Mechanical) | 50 to 55 mm |
| Product Width | 1.08 in |
| Coil Voltage Rating | 120 VAC |
| Environmental Category of Protection | RTII |
| Insulation Initial Resistance | 1,000 megaohm |
| Contact Limiting Breaking Current | 30 A |
| Contact Limiting Continuous Current | 30 A |
| Contact Voltage Rating | 277 VAC |
| Coil Power Rating AC | 1,600 VA |
| Insulation Initial Dielectric Between Open Contacts | 1,500 Vrms |
| Relay Termination Type | .25 x .032 Quick Connect Terminals |
| Insulation Creepage Between Contact & Coil | 1/4 in |
| Coil Special Features | UL Coil Insulation Class F |
| Contact Number of Poles | 1 |
| Coil Resistance | 2,800 ohms |
| Relay Mounting Type | Quick Connect |
| Environmental Ambient Temperature (Max) | 70 deg C |
| Insulation Initial Dielectric Between Coil & Contact Class | 1,500 to 2,500 V |
| Package Quantity | 1 |
