DC Power Supply, 100/120V AC; 200/240V AC, 12/15V DC, 90W, 7.5A, DIN Rail
| Item | DC Power Supply |
|---|---|
| Input Voltage | 100/120V AC; 200/240V AC |
| Output Voltage | 12/15V DC |
| Power Rating | 90 W |
| Output Amps | 7.5 A |
| Mounting | DIN Rail |
| Case Material | Plastic Case |
| Phase - Electrical | Single |
| Style | Switching |
| Height | 75 mm |
| Width | 72.5 mm |
| Depth | 103 mm |
| Hz | 50/60 Hz |
| Standards | Class I Div. 2 Canada - CSA (245 KB), Class I Div. 2 USA - CSA (245 KB), EU Declaration of Conformity, IEC 60950 CB Scheme (1 MB), IEC 61010-2-201 CB Scheme (439 KB), Marine DNV (219 KB), UK Declaration of Conformity (61 KB), UL 508 Canada, UL 508 USA, UL 60950-1 Canada, UL 60950-1 USA |
| Hold Up Time | 41 msec |
| Operating Temp. Range | -10 to 70 deg C |
| Status Indicator | Green LED |
| Series | MiniLine |
| IP Rating | IP20 |
| Output Noise | 50 mV |
| Features | High Efficiency and Long Lifetime |
| Connection | Spring Clamps |
| External input fuse recommendation | B-10A, C-6A |
| Ripple and noise voltage max. | 50 mVpp |
| Derating | 2.5W/°C for >+60°C |
| MTBF SN 29500 @ 40°C (h) | 500,000 h |
| Input inrush current limitation | NTC |
| Adjustment range | 12 to 15 V |
| Efficiency, typ. | 0.885 |
| Power factor | 0.55 |
| Power losses, typ. | 11.7 W |
| Input inrush current | 22A / 37A |
| Operating Temperature - Minimum | 14 deg F |
| Mean Time Between Failures (MTBF) | 500,000 hr |
| Current - Inrush | 37 A |
| Wire Size - Maximum | 12 AWG |
| Wire Size - Minimum | 28 AWG |
| Operating Temperature - Maximum | 158 deg F |
| Maximum Efficiency @ 230V AC | 88.5% |
| Special Features | Parallel Capability |
| Current - Output | 6 A |
| Output Power - Rated | 90 W |
| Wire Connection Type | Terminals |
| Housing Material | Plastic |
| Package Quantity | 1 |
