Heater Hanger Arm, 17" L, Steel
| Item | Gas Wall and Ceiling Heater Mounting Bracket |
|---|---|
| Material | Steel |
| For Use With | Air Handlers, Furnaces and Unit Heaters |
| Length | 17 in |
| Includes | 3/4 in Pressed-ln Swivel Bolt with Nylon Lock Nut and Cotter Pin, H Bracket, Left Arm, Right Arm, Steel and Rubber Washers, Swivel Spreader Arm with Circular Adjustment Plate, Thumb Screw, U-Bar with Circular Adjustment Plate, Wing Nut |
| Joists | 16 in, 24 in |
| Load Capacity | 200 lb |
| Overall Depth | 34-5/8 in |
| Joist Mounting Direction | Parallel, Perpendicular |
| Overall Width | 15-3/8 in |
| Compatible with Product Type | Unit Heaters, Furnaces, Air Handlers |
| Product Type | Mounting Brackets |
| Contact Points | 4 |
| Overall Height | 5-5/8 in |
| Finish | Powder Coated |
| Overall Dimensions - H x W x D | 5-5/8 in x 15-3/8 in x 34-5/8 in |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
