Extension Ring, 1 Gang, Galvanized steel, Outlet Box Type
| Item | Extension Ring |
|---|---|
| Number of Gangs | 1 Gang |
| Material | Galvanized steel |
| Nominal Length | 4 in |
| Nominal Width | 2 in |
| Nominal Depth | 1-7/8 in |
| Box Type | Outlet |
| Color | Silver |
| Number of 1/2 In. Side Knockouts | 5 |
| Number of 1/2 In. Back Knockouts | 2 |
| Capacity | 13 cu in |
| Standards | UL Listed |
| Bracket Type | A |
| Length | 6.44 in |
| Width | 2.96 in |
| Depth | 1-7/8 in |
| Height | 6.44 in |
| Features | Drawn construction with raised ground and "A" bracket which positions box against face and side of stud; 4 in. x 2 in., 1-7/8 in. deep; Supplied with seven 1/2 in. knockouts; 13.0 cu. in. capacity; Acceptable for use in 2-hour fire rated walls |
| Actual Depth | 1.88 in |
| Standard | UL Listed |
| Wiring System | Conduit |
| Certified Listed | UL Listed |
| Raised Ground | Yes |
| Drawn or Welded | Drawn |
| Overall Height | 6-7/16 in |
| Box Depth | 1 7/8 in |
| Hub Type | Not Applicable |
| Box Height | 4 in |
| Overall Width | 2-1/4 in |
| Box Width | 2-1/8 in |
| Number of 1/2 in Back Knockouts | 2 |
| Box Diameter | Not Applicable |
| Overall Depth | 1-7/8 in |
| Number of 1/2 in Side Knockouts | 5 |
| Package Quantity | 1 |
