Circular Mil Spec Strain Reliefs & Adapters Stxr40Ab00-1818Bi
| Material | Aluminum |
|---|---|
| Color | Olive Drab |
| Pluggable I/O Accessory Type | Tinel-Lock Adapter |
| Connector Shell Size | F, 19 |
| TE Adapter Code | 40 |
| Operating Temperature Range | -65 “ 175 °C |
| Termination Device Included | TR18BI |
| Adapter Entry Size | 18 |
| Salt Spray Resistance | 500 hr |
| Style | Tinel-Lock Adapter |
| Cable Entry Diameter | .01 “ 1.13 in |
| Overbraid Termination | Tinel-Lock Ring |
| Termination Device Type | Side-Entry Tinel-Lock Ring, Tinel-Lock Ring |
| Adapter Plating Material | Cadmium |
| Connector Detail Specification Number | D38999/42, D38999/47, D38999/24, D38999/26, D38999/46, D38999/20, D38999/40 |
| Cable Diameter Range | .5 “ .1 in |
| Connector General Specification Number | MIL-DTL-38999 Series IV/Class C,F,W, MIL-DTL-38999 Series III/Class C,F,K,W, MIL-DTL-38999 Series IV/Class C,W, MIL-DTL-38999 Series IV/Class F,W |
| Package Quantity | 1 |
