Label Heat Shrinkable Yellow
| Shrink Ratio | 0.084 |
|---|---|
| Material | Radiation Crosslinked Polyolefin |
| Format | Ladder |
| Recommended Ribbon | See Printer Ribbon Matrix |
| Operating Temperature Range | -55 " - 125 °C [ -67 " - 257 °F ] |
| Fluid Resistance | 24 hour fluid immersion at 24 °C |
| Recovered Inside Diameter (Max) | 19.05 mm [ .75 in ] |
| Sleeve Color | Yellow |
| Grade | LFH |
| Markers per Sleeve | 2 |
| Fire Performance | Self-Extinguishing |
| Product Type | Sleeve |
| Sleeve Length (Nominal) | 50 mm [ 1.97 in ] |
| Expanded Inside Diameter (Min) | 38.1 mm [ 1.5 in ] |
| Number of Prescores | 1 |
| Wall Thickness (Nominal) (Full Recovery) | 1 mm [ .0391 in ] |
| Compatible Cable Diameter | 20.95 " - 33.02 mm [ .825 " - 1.3 in ] |
| Package Quantity | 1 |
