Counter, 2 Line Red/Green Backlight LCD
| Item | Counter |
|---|---|
| Display | 2 Line Red/Green Backlight LCD |
| Input Signal | 1.5V DC Current Sinking, 30V DC Current Sourcing |
| Number of Digits | 6 |
| Mounting | Panel |
| Height | 1.95 in |
| Output Rating | 1/10 HP @ 120V AC, 5 A @ 250V AC, 5 A @ 30V DC |
| Output | Relay, NPN Open Collector |
| Power Required | 18 to 36 V DC, 24 V AC |
| Reset Type | Key |
| Depth | 4.54 in |
| Width | 1.95 in |
| Input Voltage | 18 to 36V DC; 24V AC |
| Character Height | 0.2 in Secondary, 0.3 in Main |
| Manufacturers Warranty Length | Limited |
| Connector Type | Wire Clamp/Screw Terminal |
| Fits | 1/16 DIN; 1.772 in x 1.772 in Panel Cutout |
| Special Features | Bi-Directional and Quadrature Counting, Red Top Line and Green Bottom Line Display |
| Diameter | 4 in |
| Min. On/Off Pulse | 10 msec |
| Scaler | Yes |
| Standards | cRUus, UKCA, UL E137808 |
| Prescaling Range | 0 to 10 |
| Preset | 1 |
| NEMA Rating | 4X |
| IP Rating | IP65 |
| Overall Depth | 4-5/8 in |
| Digit Height - Maximum | 0.3 in |
| Cutout DIN Size | 0.125 |
| Overall Width | 2 in |
| Display Features | Not Applicable |
| Overall Diameter | Not Applicable |
| Counts per Second - Maximum | Not Applicable |
| Digit Color | Green, Yellow |
| NEMA Enclosure Rating | 4X |
| Counter Display Type | LCD |
| Features | Bi-Directional and Quadrature Counting, Single Preset Version |
| Overall Height | 2 in |
| Cutout Width | 1-7/8 in |
| Count Speed - Maximum | 11 kHz |
| Mounting Style | DIN Track |
| Cutout Height | 1-7/8 in |
| Terminal Connection Type | Wire Clamping Screw |
| Output Type | Relay, NPN Open Collector |
| Package Quantity | 1 |
