RG400 Coaxial Cable Assembly with BNC M to BNC M Connectors, 50 Ohm Z, 15 ft Length
| Impedance | 50 ohms |
|---|---|
| Connector B Type | BNC |
| Operating Frequency | 4 GHz |
| Bend Radius | 1.0" |
| Jacket | Tan FEP, Type IX per MIL-C-17 |
| Style | Straight |
| Body Material | Nickel-plated brass |
| Voltage Rating | 500 V Maximum |
| Mating Cycles | 500 |
| Contact Material | Brass |
| Overall Diameter | 0.195 in |
| Gender | Male |
| Cable Type | RG-400/U Coaxial |
| Connector A Type | BNC |
| Temperature Rating | -40°C to 85°C |
| Package Quantity | 1 |
