Cable de conexión, ensamblaje Mini-Link, PVC, F, 5 pines, 20 pies.
| Item | Mini Link Plug Assembly |
|---|---|
| Cable Length | 20 ft |
| Jacket Color | Yellow |
| Max. Voltage | 600VAC/VDC |
| Wire Size | 16 AWG |
| For Use With | 12 and 18mm Proximity Sensors; Limit Switches; Photoelectric Switches; Solenoids And Hydraulic Valves; Foot Operated Switches; Power Tools; Cranes, Hoists and their Controls |
| Features | Multiple Hole Bushings in a Variety Of Hole Combinations; Slit Bushings; Embedded O-Rings; Nickel Coated then Gold Plated Contacts for Enhanced Corrosion Resistance and Conductivity; Pins and Contacts Crimped onto Wires Assuring Secure Terminations, Precision Machined Contacts for Highly Accurate Tolerances; Heavy-Duty SOOW, SJOOW or STOW Cable Options; Integral Strain Relief and Plated Coupling Nuts |
| Color | White, Red, Green, Orange, Black |
| NEMA Rating | 6P |
| Max. Amps | 8 |
| IP Rating | IP67 |
| Number of Conductors | 5 |
| Body Material | PVC |
| Temp. Range | -58 to 356 deg F |
| CSA Specification | E165657 |
| Maximum Operating Temperature (F) | 356 |
| Minimum Operating Temperature (F) | -58 |
| Package Quantity | 1 |
