MC Cable Connector, Al, 1-1/2", 1.975-2.100
| Style - Connector | Straight |
|---|---|
| Item | MC Cable Connector,Al,1-1/2",1.975-2.100 |
| Conduit Size | 1.5 |
| Standards | CSA 28985 |
| Material | Aluminum |
| Trade Size | 1-1/2 in |
| Cable Opening Min. | 1.975 in |
| Cable Opening Max. | 2.1 in |
| Knockout Size | 2.016 in |
| Maximum Knock Out Size (In) | 2.016 |
| Maximum Operating Temperature (F) | 250 |
| CSA Specification | 28985 |
| Bushing Holes | 1 |
| Minimum Operating Temperature (F) | -40 |
| Cable Range | 1.975 to 2.1 |
| Inside Body Diameter / Body Bore | 1.59 |
| Thread Type | NPT |
| Bushing Material | Neoprene |
| Thread Size | 1.5 |
| Clearance Hole (In) | 2.016 |
| Package Quantity | 1 |
