MC Cable Connector, Al, 1-1/4", 1.350-1.475
| Style - Connector | Straight |
|---|---|
| Item | MC Cable Connector,Al,1-1/4",1.350-1.475 |
| Conduit Size | 1.25 |
| Material | Aluminum |
| Standards | CSA 28985 |
| Knockout Size | 1.766 in |
| Cable Opening Min. | 1.35 in |
| Trade Size | 1-1/4 in |
| Cable Opening Max. | 1.475 in |
| Thread Type | NPT |
| Inside Body Diameter / Body Bore | 1.15 |
| Bushing Holes | 1 |
| Maximum Operating Temperature (F) | 250 |
| Bushing Material | Neoprene |
| Maximum Knock Out Size (In) | 1.766 |
| Clearance Hole (In) | 1.766 |
| Minimum Operating Temperature (F) | -40 |
| Thread Size | 1.25 |
| Cable Range | 1.35 to 1.475 |
| CSA Specification | 28985 |
| Package Quantity | 1 |
