MC Cable Connector, Al, 3-1/2", 3.750-3.900
| Style - Connector | Straight |
|---|---|
| Item | MC Cable Connector,Al,3-1/2",3.750-3.900 |
| Conduit Size | 3.5 |
| Standards | CSA 28985 |
| Material | Aluminum |
| Trade Size | 3-1/2 in |
| Knockout Size | 4.04 in |
| Cable Opening Min. | 3-3/4 in |
| Cable Opening Max. | 3.9 in |
| Bushing Material | Neoprene |
| CSA Specification | 28985 |
| Bushing Holes | 1 |
| Maximum Operating Temperature (F) | 250 |
| Clearance Hole (In) | 4.04 |
| Inside Body Diameter / Body Bore | 3.25 |
| Thread Type | NPT |
| Maximum Knock Out Size (In) | 4.04 |
| Thread Size | 3.5 |
| Cable Range | 3.75 to 3.9 |
| Minimum Operating Temperature (F) | -40 |
| Package Quantity | 1 |
