MC Cable Connector, Al, 3/4", .955-1.080
| Style - Connector | Straight |
|---|---|
| Item | MC Cable Connector,Al,3/4",.955-1.080 |
| Standards | CSA 28985 |
| Conduit Size | 0.75 |
| Material | Aluminum |
| Cable Opening Max. | 1.08 in |
| Trade Size | 3/4 in |
| Knockout Size | 1.141 in |
| Cable Opening Min. | 0.955 in |
| Bushing Material | Neoprene |
| Bushing Holes | 1 |
| Cable Range | 0.955 to 1.08 |
| Minimum Operating Temperature (F) | -40 |
| Maximum Knock Out Size (In) | 1.141 |
| Thread Type | NPT |
| Clearance Hole (In) | 1.141 |
| Thread Size | 3/4 |
| Inside Body Diameter / Body Bore | 0.81 |
| CSA Specification | 28985 |
| Maximum Operating Temperature (F) | 250 |
| Package Quantity | 1 |
