MC Cable Connector, SS, 3", 3.150-3.300
| Item | MC Cable Connector,SS,3",3.150-3.300 |
|---|---|
| Conduit Size | 3 |
| Minimum Operating Temperature (C) | -40 |
| Maximum Operating Temperature (C) | 121 |
| Bushing Holes | 1 |
| Cable Range | 3.150 - 3.300 |
| CSA Specification | 28985 |
| A Dimension (in) | 4.5 |
| B Dimension (in) | 5.68 |
| Plating Color | Natural |
| O-Ring Material | Buna N |
| Plating Type | Passivated |
| Maximum Operating Temperature (F) | 250 |
| Clearance Hole (in) | 3.625 |
| Inside Body Diameter / Body Bore | 2.8 |
| Connector Material | Stainless Steel |
| Bushing Material | Neoprene |
| Thread type | NPT |
| Maximum Knock Out Size (in) | 3.625 |
| Max Cable Range over Jacket (in) | 3.3 |
| IP Rating | IP65 |
| Min Cable Range over Armor (in) | 3.01 |
| Cord Grip Type | Straight |
| Minimum Operating Temperature (F) | -40 |
| Thread Size | 3 |
| Body Material | Stainless Steel |
| NEMA Rating | 4X |
| Min Cable Range over Jacket (in) | 3.15 |
| Max Cable Range over Armor (in) | 3.21 |
| Package Quantity | 1 |
