Takes 7 Inserts, 495-09T3M-XL Insert, Right Hand Cut, Through Coolant, Series CoroMill 495
| Minimum Cutting Diameter (mm) | 63.50 |
|---|---|
| Maximum Depth of Cut (mm) | 5.47 |
| Maximum Depth of Cut (Decimal Inch) | 0.2154 |
| Arbor Hole Diameter (mm) | 63.00 |
| Arbor Hole Diameter (Decimal Inch) | 2.4803 |
| Compatible Insert Size Code | 495-09T3M-XL |
| Cutter Style | 495..Cx |
| Cutting Direction | Right Hand |
| Series | CoroMill 495 |
| Overall Height (Decimal Inch) | 4.6457 |
| Maximum Body Diameter (Decimal Inch) | 2.4691 |
| Maximum RPM | 4700 |
| Complete Insert Compatibility | 495-09T3M-XL |
| Toolholder Material | Steel |
| Number Of Cutter Inserts | 7 |
| Coolant Through | Yes |
| UNSPSC Code | 23291600 |
| Country of Origin | UNITED STATES |
| undefined | undefined |
| MSC Number | MSC# 54949656 |
