One-Sided Deadbolt, Bright Chrome Finish
| Mortise / Cylindrical | Cylindrical |
|---|---|
| Location Type | Residential, Multi-Family |
| Lockset Grade | 1 |
| Series | B81N |
| For Door Thickness | 1-3/8 to 1-3/4 in |
| Lockset Finish | Satin Chrome |
| Keyway Type | None |
| Key Type | Not Keyed |
| Standards | ANSI/BHMA A156.2-2011 |
| ADA Compliant | No |
| Strike | Round and Square Corner |
| Backset | 2-3/8 in |
| For Use With | Various Door Types |
| Material | Brass |
| Mortise/Cylindrical | Cylindrical |
| Item | Deadbolt Lock |
| Cylinder | Single |
| Faceplate Dimensions | 1-1/8 in x 2-1/4 in |
| Strike Dim. | 1-1/8 in x 2-3/4 in |
| Ligature Resistant | No |
| Security Type | Heavy-Duty |
| Pins | 0 |
| Throw Length | 1 in |
| Lockset Fire Rating | Not Rated |
| Includes | Hardware |
| Number of Keys | 0 |
| Application | Multiple Family Residential, Residential |
| Finish | Bright Chrome |
| Hardware | Included |
| Number of Pins | 0 |
| Fire Rating | Not Applicable |
| Faceplate Height | 2-1/4 in |
| Strike Plate Height | 2-3/4 in |
| Visual Indicator Message | No Message |
| Includes Hardware | Hardware Included |
| Locking/Unlocking Access - Inside | Thumb Turn |
| Locking/Unlocking Access - Outside | Not Lockable |
| Faceplate Width | 1-1/8 in |
| Door Thickness - Maximum | 1-3/8 in |
| ANSI/BHMA Finish | Satin Chromium-Plated |
| Cylinder Core Type | Not Applicable |
| Ligature-Resistant | Not Ligature-Resistant |
| Includes Core | Core Not Included |
| ANSI Grade | 1 |
| Door Thickness - Minimum | 1-3/4 in |
| Strike Plate Width | 1-1/8 in |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
