Relevadores de estado sólido trifásicos de 50A, entrada de 18-36 VCA y salida de 48-530 VCA.
| Item - Relay | Solid State Relay |
|---|---|
| Input or Control Voltage | 18 to 36 V AC |
| Output or Controlled Voltage Range | 48 to 530 V AC |
| Max. Output Amps w/Heat Sink | 50 A |
| Heat Sink | Not Included |
| Switch Type | SCR |
| Contact Form - Relay | SPST-NO |
| Relay Turns On At | Instantaneous, Random |
| Input Power Consumption (Burden) | 0.7 W |
| Mounting - Relay | Surface |
| Input Voltage | 18 to 36V AC |
| Voltage Output | 48 to 530 VAC |
| Item | Solid State Relay |
| Case Color | Dark Gray |
| Body Height - Relay | 1.4 in |
| Body Width - Relay | 4 in |
| Finger Safe | Yes |
| Body Depth - Relay | 3.14 in |
| Mounting | Flange |
| Max. Output w/Heat Sink | 50 A |
| Standards | CE Certified, CSA Certified, IEC 60950-1, IEC 61000, IEC 62314, UL Listed |
| Input or Control Voltage Range | 18 to 36VAC |
| Overall Height - Relay | 1.4 in |
| Green Environmental Attribute | Does not Contain Formaldehyde |
| Turns On At | Random Cross |
| Phase | 3 |
| Max. Output Amps Without Heat Sink | Not Recommended |
| Includes | Thermal Pad |
| Voltage Type | AC Output |
| Maximum Switching Voltage | 2 V AC |
| Power Factor | 0.5 |
| Switch Component Type | SCR |
| Body Height | 3.13 in |
| Drop Out Voltage | 1.35 V DC |
| Output Switching Mode | Instantaneous, Random |
| Input Current | 15 to 20 mA |
| Maximum Output Current without Heat Sink | Not Recommended |
| Response Time | 30 msec |
| Body Width | 3.98 in |
| Insulation Resistance | 1,000 megaohm |
| Minimum Switching Voltage | 18 V AC |
| Series | Harmony(TM) SSP Series |
| Status Indicator | Green LED Indicator |
| Minimum Operating Temperature | -40 deg F |
| Body Depth | 1.39 in |
| Current Type | AC |
| Maximum Operating Temperature | 176 deg F |
| IP Rating | IP20 |
| Maximum Capacitance | 8 pF |
| Dielectric Strength | 4,000V AC |
| Weight | 8.48 oz |
| Output Voltage Range | 48 to 530 V AC |
| Horsepower @ 240V AC | 3 HP |
| Maximum Output Current with Heat Sink | 50 A |
| Electrical Phase | Three |
| Mounting Style | Panel |
| Switch Configuration | Form A |
| Electrical Connection | Screw Clamp |
| Overall Depth | 1.39 in |
| Package Quantity | 1 |
