Circuit Breaker, GB2 Series, 10A, 1 Pole, 250/277V AC, 1.5kA at 240V AC/24V DC
| Item | Circuit Breaker |
|---|---|
| Series | GB2 |
| Amps | 10A |
| Number of Poles | 1 |
| AC Voltage Rating | 250/277V AC |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | DIN Rail |
| Max. AIR Rating | 1.5kA at 240V AC/24V DC |
| Trip Type | Thermal Magnetic |
| Terminal Connection | Connectors |
| Width | 0.59 in |
| Depth | 2.64 in |
| Height | 2.91 in |
| DC Voltage Rating | 48V DC |
| Interrupt Rating | 2 kA at 110V AC, 1.5 kA at 230/240V AC/24V DC |
| Application | Control Applications |
| Features | Mercury Free |
| Standards | CSA, IEC, UL |
| High Amp Trip Setting | 138 A |
| Package Quantity | 1 |
