Circuit Breaker, GB2 Series, 5A, 1 Pole, 250/277V AC, 2kA at 240V AC
| Item | Circuit Breaker |
|---|---|
| Series | GB2 |
| Amps | 5A |
| Number of Poles | 1 |
| AC Voltage Rating | 250/277V AC |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | DIN Rail |
| Max. AIR Rating | 2kA at 240V AC |
| Trip Type | Thermal Magnetic |
| Terminal Connection | Connectors |
| Width | 0.59 in |
| Depth | 2.64 in |
| Height | 2.91 in |
| DC Voltage Rating | 48V DC |
| Features | Mercury Free |
| High Amp Trip Setting | 66 A |
| Application | Control Applications |
| Interrupt Rating | 3 kA at 110V AC, 2 kA at 230/240V AC, 1.5 kA at 24V DC, 1 kA at 48V DC |
| Standards | CSA, IEC, UL |
| Package Quantity | 1 |
