Cabeza para botón de pulsador sin iluminación, Harmony XB4, metal, a ras, negro, 22mm, retorno por resorte, marcado con FLECHA ABAJO
| Item | Flush Black With White Up Arrow Marking |
|---|---|
| Type of Operator | spring return |
| NEMA Rating | NEMA 13 || NEMA 4X |
| Standards | UL || CSA |
| IP Rating | IP66 IEC 60529 || IP67 || IP69 || IP69K |
| Depth | 28 mm |
| Height | 29 mm |
| Width | 29 mm |
| Header | standard |
| Protective Treatment | TH |
| Bezel Material | chromium plated metal |
| Ambient Air Temperature For Storage | -40-70°C |
| Mechanical Durability | 10,000,000 cycle |
| Device Presentation | basic element |
| Electrical Composition Code | C1 9 single front mounting, C2 9 single and double front mounting, C11 3 single front mounting, C15 1 single front mounting |
| Shape of Signaling Unit Head | round |
| Ambient Air Temperature For Operation | -40-70°C |
| Ik Degree of Protection | IK06 conforming to IEC 50102 |
| Cap/Operator or Lens Colour | black |
| Device Short Name | ZB4 |
| Range of Product | Harmony XB4 |
| Overvoltage Category | class I IEC 60536 |
| Mounting Diameter | 22.5 mm |
| Shock Resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Product or Component Type | head for non-illuminated push-button |
| Vibration Resistance | 5 gn 2-500 Hz)IEC 60068-2-6 |
| Package Quantity | 1 |
