Bobina de contactor IEC
| Item | Replacement Coil |
|---|---|
| Coil Volts | 120 V AC |
| For Use With | LC1D40, 50, 65, 80 |
| Hz | 60 |
| Contactor Type | IEC |
| [Uc] Control Circuit Voltage | 120 V AC 50/60 Hz |
| Coil Technology | without built-in suppressor module |
| Product Compatibility | LC1D40 || LC1D50 || LC1D65 to D95 |
| Hold-In Power Consumption In Va | 26-26 VA 60 Hz 0.3 20 °C) || 26-26 VA 50 Hz 0.3 20 °C) |
| Device Short Name | LX1D6 |
| Inrush Power In Va | 245-245 VA 60 Hz 0.75 20 °C) || 245-245 VA 50 Hz 0.75 20 °C) |
| Average Resistance | 32 Ohm 20 °C |
| Range | TeSys |
| Inductance Of Closed Circuit | 2 H |
| Maximum Operating Rate | 3600 cyc/h 60 °C |
| Control Circuit Type | AC 50/60 Hz |
| Heat Dissipation | 6-10 W 50/60 Hz |
| Mechanical Durability | 4 Mcycles |
| Ambient Air Temperature For Operation | -5-60 °C |
| Product Or Component Type | contactor coil |
| Control Circuit Voltage Limits | drop-out 0.3 to 0.6 Uc 50/60 Hz 55 °C) || operational 0.8 to 1.1 Uc 50 Hz 55 °C) || operational 0.85 to 1.1 Uc 60 Hz 55 °C) |
| Compatible with Series | LC1D40 Contactors, LC1D50 Contactors, LC1D65 to D95 Contactors, TeSys Deca |
| Contactor Style | IEC |
| Coil Power | 220 VA |
| Coil Voltage | 120V AC |
| NEMA Size | Not Applicable |
| Frequency | 50/60 Hz |
| Package Quantity | 1 |
