Módulo, 60 mm, Negro, Verde
| Item | Module |
|---|---|
| For Use With | Harmony XB5R Series |
| Features | 1 LED, Wireless |
| Color | Black, Green |
| Standards | BTL, CSA, EN/IEC 60730-1, EN/IEC 61000-6-1, UL 508, UL 60730-1, UL 873 |
| Pollution Degree | 2 |
| Marking | CE |
| Integrated Connection Type | Ethernet RJ45 - 2 twisted pairs - class D |
| Local Signalling | for transmission activity 1 LED || for reception activity (RX) 1 LED || for module status 1 LED || for network status 1 LED |
| Ip Degree Of Protection | IP20 |
| Communication Service | static IP || DHCP, Modbus TCP/IP || BOOTP |
| Relative Humidity | 5-95 % without condensation |
| Shock Resistance | 15 gn 11 ms |
| Transmission Rate | 10/100 Mbit/s |
| Communication Port Protocol | Modbus TCP |
| Ambient Air Temperature For Operation | -20-65°C |
| Product Destination | ZBRN1 wireless Harmony Hub |
| Product Or Component Type | communication module |
| Vibration Resistance | 1.5 mm 3-13 Hz) || 1 mm 13-23 Hz) || 2 gn 23-150 Hz) |
| Physical Interface | RJ45 - 10BASE-T || RJ45 - 100BASE-TX |
| Operating Altitude | 0 to 6561.68 ft (0 to 2000 m) |
| Storage Altitude | 0-3048 m |
| Product Certifications | CSA || UL 508 || BTL || UL 873 || UL 60730-1 |
| Electromagnetic Compatibility | EMC immunity EN/IEC 61000-6-1 || EMC immunity level 2 EN/IEC 60730-1 || electrostatic discharge level 3B IEC 61000-4-2 || radiated RF fields level 3A IEC 61000-4-3 || electrical fast transient/burst immunity test level 4B IEC 61000-4-4 || surge immunity test level 3 IEC 61000-4-5 || conducted RF disturbances level 3A IEC 61000-4-6 || conducted EMC level 2 EN/IEC 60730-1 || conducted EMC EN/IEC 61000-6-3 || EMC immunity IEC 61800-3 || conducted EMC IEC 61800-3 category C1 |
| Ambient Air Temperature For Storage | -25-70°C |
| Device Short Name | ZBRCETH |
| Compatible with Series | XB5R |
| Compatible Product Type | Harmony Hub |
| Compatible with Manufacturer Model Number | ZBRN1 |
| Package Quantity | 1 |
