Plate, 690V, 25A, 3 Poles
| Item | Plate |
|---|---|
| Voltage | 690V |
| Amps | 25A |
| Number of Poles | 3 |
| Width | 54 mm |
| Height | 190 mm |
| Standards | IEC 60439 |
| Depth | 61 mm |
| Number Of Cables | 3 4-4 mm2² 105 2°C |
| [Ith] Conventional Free Air Thermal Current | 25 A |
| I²T On Activation | 200000 A2².s |
| Product Name | HK |
| 9 Mm Pitches | 6 |
| Net Weight | 0.23 kg |
| Product Certifications | UL || DNV || CSA || LROS |
| Range | Linergy |
| [Ui] Rated Insulation Voltage | 690 V IEC 60439-1 |
| Product Or Component Type | plate |
| Package Quantity | 1 |
