Relé de conexión, Relevadores de estado sólido Harmony, 2A, conmutación de voltaje cero, entrada de 15 a 30V DC, salida de 24 a 280V AC.
| Item | SsrSlim,1 Chann 2A@24-280VAC Zero,15-30 |
|---|---|
| Response Time | 0.5 cycle (turn-on) || 0.5 cycle (turn-off) |
| Depth | 15 mm |
| Height | 28 mm |
| Width | 5 mm |
| Dielectric Strength | 2500 V for input/output |
| Maximum Switching Voltage | 10 V DC turn-off |
| Dv/Dt | 500 V/µs off-state at maximum voltage |
| Overvoltage Category | III |
| Absolute Maximum Voltage | 600 V AC |
| Input Impedance | 3500 Ohm |
| Surge Current | 120 A 16.6 ms || 115 A 20 ms |
| Pollution Degree | 2 |
| Mounting Support | socket |
| Output Voltage | 24...280 V AC |
| Marking | CE |
| Flame Retardance | V0 conforming to UL 94 |
| Maximum Voltage Drop | <1.1 V on-state |
| Maximum I²T For Fusing | 66 A².s for 10 ms at 50 Hz || 60 A².s for 8.3 ms at 60 Hz |
| Minimum Switching Voltage | 15 V DC turn-on |
| Product Certifications | UL || CSA |
| Line Rated Current | 2 A |
| Ambient Air Temperature For Storage | -20-85°C |
| Capacitance Unbalance | 1.5 pF input/output |
| Phase | 1 phase |
| Product Or Component Type | solid state relay up to 10 A |
| Maximum Leakage Current | 4 mA off-state |
| Output Switching Mode | DC switching |
| Device Short Name | SSL |
| Solid State Output Type | zero voltage switching || SCR output |
| Ambient Air Temperature For Operation | -20-80°C |
| Input Current Limits | 6 to 6 mA |
| [Uc] Control Circuit Voltage | 15...30 V DC |
| Load Current | 0.07-2 A |
| Range of Product | Harmony Solid State Relays |
| Package Quantity | 1 |
