Relevador de inserción, Relevadores de Estado Sólido Delgados Harmony, 3.5A, conmutación de CD, entrada de 15 a 30V CD, salida de 1 a 24V CD.
| Standards | UL, CSA |
|---|---|
| Response Time | 0.35 ms (turn-on), 0.08 ms (turn-off) |
| Item | SsrSlim,1 Channel 3.5A@1-24VDC,15-30VDC |
| Width | 5 mm |
| Height | 28 mm |
| Depth | 15 mm |
| Dielectric Strength | 2500 V for input/output |
| Product or Component Type | solid state relay up to 10 A |
| Capacitance Unbalance | 1.5 pF input/output |
| Overvoltage Category | III |
| Load Current | 0.001-3.5 A |
| Ambient Air Temperature For Storage | -20-85°C |
| Range of Product | Harmony Solid State Relays |
| Mounting Support | socket |
| Pollution Degree | 2 |
| Surge Current | 9 A 10 ms |
| Marking | CE |
| Input Current Limits | 7 to 7 mA |
| Absolute Maximum Voltage | 30 V DC |
| Maximum Voltage Drop | <0.5 V on-state |
| Solid State Output Type | Mosfet output, DC switching |
| Line Rated Current | 3.5 A |
| [Uc] Control Circuit Voltage | 15...30 V DC |
| Output Switching Mode | DC switching |
| Input Impedance | 3500 Ohm |
| Maximum Operating Frequency | 500 Hz |
| Phase | 1 phase |
| Minimum Switching Voltage | 15 V DC turn-on |
| Maximum Leakage Current | 0.001 mA off-state |
| Device Short Name | SSL |
| Maximum Switching Voltage | 10 V DC turn-off |
| Ambient Air Temperature For Operation | -20-80°C |
| Output Voltage | 1...24 V DC |
| Flame Retardance | V0 conforming to UL 94 |
| Product Certifications | UL || CSA |
| Package Quantity | 1 |
