Bloque de contacto sencillo, Harmony XB4, aleación de plata, conector Faston, 1NA
| Item | N/O Contact With QcS |
|---|---|
| Standards | IEC 60947-5-4, JIS C8201-5-1, UL 508, CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, JIS C8201-1 |
| [Ui] Rated Insulation Voltage | 250 V 3)IEC 60947-1 |
| Protective Treatment | TH |
| Ambient Air Temperature For Storage | -40-70°C |
| Operating Force | 2.3 N NO changing electrical state |
| Ambient Air Temperature For Operation | -40-70°C |
| Vibration Resistance | 5 gn 2-500 Hz)IEC 60068-2-6 |
| Operating Travel | 2.6 mm NO changing electrical state), 4.3 mm total travel) |
| Mounting of Block | front mounting |
| Contact Block Type | single |
| Contacts Usage | contacts |
| Connections - Terminals | Faston connector 1 x 6.35 mm, Faston connector 2 x 2.8 mm |
| Ip Degree of Protection | IP20 IEC 60529 |
| Range of Product | Harmony XB5, Harmony XB4 |
| Electrical Composition Code | C1 9 ), C2 7 ), C3 6 ), C4 4 ), C5 5 ), C6 3 ), C7 4 ), C8 2 ), C9 3 ), C12 6 ), M1 6 ), M2 4 ), M3 4 ), M5 2 ), M6 2 ), M7 6 ), M8 4 ), M9 2 ), SF1 3 ), SF2 2 ), MF1 2 ), MF2 2 ), C10 2 ), M4 2 ), C13 1 ) |
| Positive Opening | without |
| Product or Component Type | contact block |
| Contact Operation | slow-break |
| Mechanical Durability | 10,000,000 cycle |
| Device Short Name | ZBE |
| Shock Resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Contacts Type And Composition | 1 NO |
| Contacts Material | silver alloy |
| Product Certifications | GL || CSA || UL || DNV || LROS (Lloyds register of shipping) || BV |
| Package Quantity | 1 |
