Relé de retardo de tiempo, 24V CA/CD, 11 pines.
| Item - Relay | Relay |
|---|---|
| Function - Timing Relay | Off Delay |
| Coil Volts | 24V AC/DC |
| Input or Control Voltage | 24 V AC/DC |
| AC Contact Rating - Relay | 10A @ 240V |
| Base Type - Plug In Relay | Octal |
| Number of Pins - Relay | 11 |
| Mounting - Relay | Plug In |
| Min. Time Setting - Timer | 30 sec |
| Contact Form - Relay | DPDT |
| Power Consumption - Relay | 2 VA |
| Max. Time Setting - Timer | 30 sec |
| Bezel Face Shape | tubular |
| Body Width - Relay | 1.69 in |
| Electrical Connection | Socket |
| Contact Material | Silver Nickel |
| Hz - Electrical | 50 Hz, 60 Hz |
| Adjustment Method | Not Applicable |
| Overall Height - Relay | 2.4 in |
| Socket | 5B584, 5B585 |
| Body Depth - Relay | 4.09 in |
| Input Voltage | 24V AC/DC |
| Standards | CE Certified, CSA Certified, UL Listed, UL Recognized |
| Item | Time Delay Relay |
| Contact Form | DPDT |
| Body Height - Relay | 2.4 in |
| Status Indicator | None |
| Socket Code | B |
| Depth | 104 mm |
| Power Consumption | 2 VA |
| Minimum Time Setting | 0.1 sec |
| Frequency | 50/60 Hz |
| Coil Voltage | 24V AC/DC |
| Body Depth | 4.09 in |
| Sealing | Sealed |
| Number of Pins | 11 |
| Body Width | 1.69 in |
| Maximum Operating Temperature | 150.8 deg F |
| Contact Rating (DC) | 10 A @ 30 V |
| Compatible with Manufacturer Model Number | 8501NR61, 8501NR62 |
| Overall Depth | 2.4 in |
| Mounting Style | Plug-In |
| Body Height | 2.4 in |
| Maximum Time Setting | 30 sec |
| Reset Method | Time-Limit Reset |
| Minimum Operating Temperature | -18.4 deg F |
| Base Shape | Octal |
| Current Rating | 10 A |
| Number of Delay Functions | 1 |
| Maximum Switching Voltage | 240 V AC |
| Contact Rating (AC) | 10 A @ 120/240V |
| Delay Function | Off Delay |
| Flat Pin Width | Not Applicable |
| Package Quantity | 1 |
