Interruptor USB iluminado, HMI Magelis GTO.
| Item | USB Switch |
|---|---|
| For Use With | HMI Magelis GTO |
| Includes | (3) Sheet of Label, Anti-Rotation Tee, Gasket, Illuminated Switch, Installation Nut, Tightening Wrench, USB Type B Cable Clamp |
| Voltage | 4.75 to 5.25V DC |
| Depth | 28 mm |
| Height | 54 mm |
| Width | 122 mm |
| Standards | CSA C22.2 No 142 || UL 508 || CSA C22.2 No 213 || EN 61000-6-4 || ANSI/ISA 12.12.01 || EN 61000-6-2 || EMC 2004/108/EC |
| Mounting Location | flat surface |
| Product Certifications | GOST || UL/cUL listed || C-tick || CE |
| Control Type | 5 push-buttons multi-colour backlit LED |
| Electromagnetic Compatibility | electrostatic discharge immunity test 8 kV air discharge) IEC 61000-4-2 || electrostatic discharge immunity test 6 kV contact discharge) IEC 61000-4-2 || electrical fast transient/burst immunity test 2 kV power ports) IEC 61000-4-4 || electrical fast transient/burst immunity test 1 kV signal ports) IEC 61000-4-4 |
| Vibration Resistance | 3.5 mm 5-9 Hz)IEC 61131-2 |
| Colour Of Cover | front dark grey |
| Level Or Class | Class I Division 2 Groups A/B/C/D |
| [Us] Rated Supply Voltage | 5 V DC USB 2.0 |
| Environmental Characteristic | corrosive gas free |
| Relative Humidity | 10-90 % 0-55°C non-condensing |
| Software Designation | Vijeo Designer >= V6.1 SP2 |
| Power Consumption In W | 2 W |
| Nema Degree Of Protection | NEMA 4X indoor installation || NEMA 13 enclosed outdoor |
| Ambient Air Temperature For Storage | -20-60°C |
| Shock Resistance | 147 m/s²3 chocks in each direction X, Y and Z IEC 61131-2 |
| Ip Degree Of Protection | IP65 front panel (in enclosure)) |
| Product Compatibility | XBTGC - controller panel || XBTGT2 to - advanced touch panel || HMISTO - touch panel || HMISCU - touch panel || XBTGT6 to - advanced touch panel || HMIGTW - advanced touch panel || XBTGK - graphic display || XBTGT4 to - advanced touch panel || XBTGT5 to - advanced touch panel || XBTGT7 to - advanced touch panel || HMISTU - touch panel || HMIGTO - advanced touch panel || HMIPSP - S-Panel PC || HMIPSO - S-Panel PC || HMIBMU - Modular Box PC || HMIBMP - Modular Box PC || HMIBMO - Modular Box PC || HMIBMI - Modular Box PC |
| Pollution Degree | 2 |
| Supply Voltage Limits | 4.75-5.25 V DC |
| Device Application | food and beverage || industrial machines |
| Connector Type | USB type B |
| Product Or Component Type | illuminated USB switch |
| Operating Altitude | <= 6561.68 ft (2000 m) |
| Provided Equipment | 1 x User Manual || 1 x USB type B cable clamp || 1 x fixing nut || 1 x tightening wrench || 1 x anti-rotation tee || 1 x gasket || 1 x insert label || 1 x USB cable type A/B 1 m |
| Package Quantity | 1 |
