Screw, Uses 9 Inserts, RP 1204 Inserts, 18 Tooth, Staggered Teeth
| Connection Type | Arbor |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 3.2090 |
| Hole Diameter (Inch) | 1-1/2 |
| Hole Diameter (Decimal Inch) | 1.5000 |
| Cutter Diameter (Decimal Inch) | 10.0000 |
| Cutter Diameter (Inch) | 10 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 9 |
| Compatible Insert Style | RP 1204 |
| Compatible Insert Size Code | 1204 |
| Tooth Type | Staggered |
| Rake | Neutral (Radial); Positive (Axial) |
| Series | R335.18 |
| Toolholder Style | R335.18 |
| Hub Diameter (Decimal Inch) | 3.5000 |
| Hub Diameter (Inch) | 3-1/2 |
| Keyway Width (Decimal Inch) | 0.6300 |
| Maximum RPM | 6000 |
| Tool Application | Side Milling |
| Tool Performance | General Purpose |
| Minimum Cutting Width (Decimal Inch) | 0.4720 |
| Maximum Cutting Width (Decimal Inch) | 0.5910 |
| Radius | Yes |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Cutter Body Width (Decimal Inch) | 0.5910 |
| Manufacturers Catalog Number | R335.18-10.00-XL0809N-R6 |
| Number Of Teeth | 18 |
| Coolant Through | No |
| Complete Insert Compatibility | RP..1204 |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 42719351 |
