Screw, Uses 7 Inserts, SNHQ Inserts, 14 Tooth, Staggered Teeth
| Connection Type | Arbor |
|---|---|
| Cutting Width (mm) | 6.35 |
| Cutting Width (Inch) | 1/4 |
| Maximum Depth of Cut (Decimal Inch) | 1.9490 |
| Maximum Depth of Cut (mm) | 49.53 |
| Hole Diameter (Inch) | 1-1/4 |
| Hole Diameter (Mm) ( - 0 Decimals) | 31.75 |
| Hole Diameter (Decimal Inch) | 1.2500 |
| Cutter Diameter (Decimal Inch) | 6.0000 |
| Cutter Diameter (Inch) | 6 |
| Cutter Diameter (mm) | 152.40 |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 7 |
| Compatible Insert Style | SNHQ |
| Compatible Insert Size Code | 1204.. |
| Tooth Type | Staggered |
| Rake | Negative (Axial); Negative (Radial) |
| Series | 335.19 |
| Toolholder Style | 335.19 |
| Hub Diameter (Decimal Inch) | 1.8750 |
| Hub Diameter (mm) | 47.75 |
| Hub Diameter (Inch) | 1-7/8 |
| Keyway Width (Inch) | 5/16 |
| Keyway Width (Decimal Inch) | 0.3120 |
| Maximum RPM | 10000 |
| Tool Application | Disc Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P |
| Minimum Cutting Width (Decimal Inch) | 0.2500 |
| Minimum Cutting Width (Inch) | 1/4 |
| Maximum Cutting Width (Decimal Inch) | 0.2890 |
| Radius | No |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Cutter Body Width (Decimal Inch) | 0.2890 |
| Cutter Body Width (mm) | 12.70 |
| Weldon Flat | No |
| Manufacturers Catalog Number | 335.19-06.00-0.25-7 |
| Insert Inscribed Circle (mm) | 0.50 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Number Of Teeth | 14 |
| Coolant Through | No |
| Complete Insert Compatibility | SNHQ1204..L+R; 335.19-1204 |
| Country of Origin | France |
| MSC Number | MSC# 53095519 |
