Screw, Uses 4 Inserts, SNHQ Inserts, 8 Tooth, Staggered Teeth
| Connection Type | Arbor |
|---|---|
| Cutting Width (Inch) | 7/8 |
| Maximum Depth of Cut (Decimal Inch) | 0.8660 |
| Maximum Depth of Cut (mm) | 22.00 |
| Hole Diameter (Mm) ( - 0 Decimals) | 22.00 |
| Hole Diameter (Decimal Inch) | 0.8660 |
| Cutter Diameter (Decimal Inch) | 3.1500 |
| Cutter Diameter (mm) | 80.00 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 4 |
| Compatible Insert Style | SNHQ |
| Compatible Insert Size Code | 1204.. |
| Tooth Type | Staggered |
| Rake | Negative (Axial); Negative (Radial) |
| Series | R335.19 |
| Toolholder Style | R335.19 |
| Hub Diameter (Decimal Inch) | 1.5750 |
| Hub Diameter (mm) | 40.00 |
| Keyway Width (Decimal Inch) | 0.4090 |
| Maximum RPM | 8400 |
| Tool Application | Side Milling; Disc Milling; Slotting |
| Tool Performance | General Purpose |
| Minimum Cutting Width (Decimal Inch) | 0.2760 |
| Maximum Cutting Width (Decimal Inch) | 0.3150 |
| Maximum Cutting Width (mm) | 8.00 |
| Radius | No |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Cutter Body Width (Decimal Inch) | 0.3150 |
| Manufacturers Catalog Number | R335.19-080.07.22-4 |
| Insert Inscribed Circle (mm) | 0.50 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Number Of Teeth | 8 |
| Coolant Through | No |
| Complete Insert Compatibility | SNHQ12045..L+R; SNHQ1204..L+R |
| Country of Origin | France |
| undefined | undefined |
| MSC Number | MSC# 45730975 |
