Solar Power Kit, 340W, 448A, 12VDC
| Item | Solar Power Kit |
|---|---|
| Number of Solar Panels | 1 |
| Individual Solar Panel Wattage | 340 W |
| For Use With | Cameras, Cathodic Protection, Communications Devices, Flow Meters, Other Electronic Devices, Railroad Applications, RTU/SCADA, Seismic Monitoring |
| Mounting | 45 Degrees /5 Degrees Welded Aluminum Mounting Bracket for 4 in OD Round Pole or Larger |
| Voltage | 12.0V DC |
| Power Rating | 340W |
| Effective Projected Area EPA | 19.32 sq ft |
| Mounting Hardware | Included |
| Modes of Operation | Always On, Motion Activation, Other Controls Available, Timers |
| Weight | 483 lb |
| Standards | Meets AASHTO Wind Requirements |
| Enclosure Material | Vented Aluminum |
| Nominal Output Power | 340 W |
| Battery Type | Gel Cell |
| Includes | Flex Tube, Full 12 ga. Wiring Harness, Liquid Tight Connectors, Quick Connect Terminals, Stainless Steel Hardware for Mounting Solar Array and Battery Box to Bracket |
| Features | Aluminum Protective Solar Panel Pan |
| Battery Capacity | 448 Ah |
| Number of Cells | 72 |
| Maximum Power Point | 340 W |
| Solar Panel Frame Material | Aluminum |
| Includes Battery | Yes |
| Total System Power Output | 340 W |
| Voltage @ Maximum Power Point | 41.6 V DC |
| Battery Voltage | 12 V DC |
| Includes Mounting Hardware | Yes |
| Package Quantity | 1 |
