240VCA Contactor Magnético de No Reversión 3P 90A NEMA 3
| Item | Magnetic Contactor |
|---|---|
| Full Load Amps | 90 A |
| Action | Non-Reversing |
| Number of Poles | 3 |
| NEMA Contactor Size | 3 |
| Coil Volts | 240 V AC |
| Reversing | No |
| Height | 6.13 in |
| HP @ 3 Phase - 208V | 25 hp |
| Width | 5.13 in |
| HP @ 3 Phase - 240V | 30 hp |
| Depth | 5-1/2 in |
| HP @ 3 Phase - 575V | 50 hp |
| HP @ 3 Phase - 480V | 50 hp |
| Enclosure NEMA Rating | No Enclosure |
| Standards | REACH Art 33 |
| Auxiliary Contact Form | 1NO |
| Hz | 60 |
| Frame / Series / Class / Code | Class 40 |
| NEMA Size | 3 |
| Series | 40 |
| Coil Voltage | 110-120/220-240V AC |
| Number of Auxillary Contacts | 1 |
| Horsepower @ Three Phase - 240V AC | 30 HP |
| Full Load Current - Resistive | Not Rated |
| Terminal Connection Type | Screw Terminals |
| Frequency | 60 Hz |
| Overall Width | 5-1/2 in |
| Horsepower @ Three Phase - 208V AC | 25 HP |
| Mounting Postion | Vertical |
| Auxiliary Contact Module Capacity | 8 |
| Horsepower @ Three Phase - 480V AC | 50 HP |
| Phase | Three |
| Horsepower @ Three Phase - 600V AC | 50 HP |
| Number of Normally Open Main Contacts | 3 |
| Includes Auxiliary Contacts | Yes |
| Mechanical Operating Durability | 5,000,000 |
| NEMA Enclosure Rating | No Enclosure |
| Maximum Operating Temperature | 104 deg F |
| Response Time | 14 to 19 msec (OFF-Delay Time), 26 to 41 msec (ON-Delay Time) |
| Embedded Surge Suppressor | No |
| Mounting Style | Surface |
| Number of Normally Closed Main Contacts | 0 |
| Contactor Style | NEMA |
| Full Load Current - Inductive | 90 A |
| Reversing Capability | Non-Reversing |
| Overall Height | 6.13 in |
| Minimum Operating Temperature | -4 deg F |
| Maximum Voltage Rating | 600 V AC |
| Overall Depth | 5.06 in |
| NEMA Enclosure Material | Not Applicable |
| Package Quantity | 1 |
