Analog Input 6ES72314HF320XB0
| Height | 100 millimetre |
|---|---|
| Depth | 75 millimetre |
| Width | 45 millimetre |
| Input, current present | Yes |
| description of product type | SM 1231, AI 8x13 bit |
| Resolution of the analog inputs | 12 bit |
| Input, thermoelement present | No |
| Performance level acc. to EN ISO 13849-1 | Without |
| Number of analog outputs | 0 |
| Explosion protection categories for gases | ATEX gas-ex-protection, Cat. 3 |
| Design of electrical connection | Screw/spring connection |
| analog inputs, configurable | Yes |
| Power loss, static, current-independent [Pls] | 2 W |
| Functional safety (SIL) | Without |
| Input, resistance thermometer present | No |
| Manufacturer product family | S7-1200 |
| Input, voltage present | Yes |
| Input signal can be configured | Yes |
| Input, resistance present | Yes |
| Manufacturer product root | Analog module input |
| Number of analog inputs | 8 |
| Package Quantity | 1 |
