Control Unit 6SL32440BB121FA0
| Power loss [W] maximum [W] | 5.5 |
|---|---|
| Load at analog output when selecting operating mode: voltage mode minimum [kOhm] | 10 |
| Product Type Designation | G120 |
| Design of the interface for bus system Integrated Note | 2 x RJ45, device name storable on device, max. 100 Mbits/s (Full Duplex) |
| Relative humidity maximum [%] | 95 |
| Load at analog output when selecting operating mode: current mode maximum [Ohm] | 500 |
| Operating voltage from power module [V] | 24 |
| Product component PC interface | Yes |
| Input voltage at digital standard inputs for signal <0> to <1> [V] | 11 |
| Ambient temperature during storage minimum [°C] | -40 |
| Number of digital inputs with fail-safe Note | Use of 2 — DI Standard |
| Product function vector control without encoder | Yes |
| Product function Torque control without encoder | Yes |
| Connectable conductor cross-section for signal line maximum [mm2] | 1.5 |
| AWG number as coded connectable conductor cross section for signal line maximum | 16 |
| Output voltage at analog output when selecting operating mode: voltage mode [V] | 10 |
| Ambient temperature [°F] during storage minimum [°F] | -40 |
| Ambient temperature [°F] during operation maximum [°F] | 131 |
| Number of interfaces acc. to PROFINET | 2 |
| Certificate of suitability for CE marking | Low-voltage directive 2006/95/EC |
| A/D resolution at the analog input [bit] | 10 |
| Number of analog inputs Note | The differential analog inputs can be configured as supplementary digital inputs |
| Certificate of suitability | UL, cUL, CE, C-Tick (RCM) |
| Output voltage of digital outputs as transistor with resistive load at DC [V] | 30 |
| Width [mm] | 73 |
| Number of interfaces acc. to RS 485 | 0 |
| Output current at analog output when selecting operating mode: current mode [mA] | 20 |
| Output voltage at the digital outputs as relay change-over contact with resistive load at DC [V] | 30 |
| Input current at digital standard inputs maximum [mA] | 15 |
| Protection class IP | IP20 |
| Number of interfaces acc. to RS 232 | 1 |
| Operating voltage from external supply voltage minimum [V] | 20.4 |
| Input voltage at analog inputs as voltage inputs for signal <0> to <1> [V] | 4 |
| Output current of digital outputs as transistor with resistive load at DC [A] | 0.5 |
| Input voltage at analog inputs as voltage inputs for signal <1> to <0> [V] | 1.6 |
| Protocol is supported PROFIsafe protocol | Yes |
| Ambient temperature during operation maximum [°C] | 55 |
| Design of the interface for control units | Basic Operator Panel BOP-2 or Intelligent Operator Panel IOP |
| Ambient temperature during operation minimum [°C] | -10 |
| Protocol is supported EtherNet/IP protocol | Yes |
| Design of the interface for PC interface | USB |
| Number of digital inputs with fail-safe | 1 |
| Type of analog input | Differential input |
| Protocol is supported TCP/IP | Yes |
| Height [mm] | 199 |
| Design of the interface of the control unit of the storage medium | 1 Sinamics Micro Memory Card (MMC) or 1 Sinamics SD Card |
| Protection function of analog input Overvoltage protection Note | Analog inputs are protected against inputs in a voltage range of±30 V and have a common mode voltage in the range of±15 V |
| Product function for U/f control ECO mode linear or quadratic | Yes |
| Number of interfaces acc. to RS 422 | 0 |
| Number of interfaces acc. to 20 mA (TTY) | 4 |
| Product function for U/f control linear or quadratic parameterization | Yes |
| Number of digital outputs as transistor | 1 |
| Application range | for modular Sinamics G120 inverters. |
| Number of interfaces parallel | 0 |
| Product component optical interface | No |
| AWG number as coded connectable conductor cross section for signal line minimum | 30 |
| Protocol for bus system for integrated interface | PROFIdrive Profile V4.1 |
| Number of interfaces acc. to USB | 1 |
| Cover version | No cover necessary |
| Ambient temperature [°F] during operation minimum [°F] | 14 |
| Product function for U/f control flux current control | Yes |
| Product Group | 9,779 |
| Input voltage at digital standard inputs for signal <1> to <0> [V] | 5 |
| Output current of digital outputs as relay change-over contact with resistive load at DC [A] | 0.5 |
| Equipment marking acc. to DIN EN 81346-2 | K |
| Type of analog output Note | Switchable between voltage and current using a parameter |
| Number of digital outputs as relay change-over contact | 2 |
| Design of the interface removable plug-in terminals | Yes |
| Consumed current maximum [A] | 0.5 |
| Protocol is supported other protocols | No |
| Protocol is supported PROFINET IO protocol | No |
| Connectable conductor cross-section for signal line minimum [mm2] | 0.05 |
| Protection function of analog outputs Short-circuit protection | Yes |
| Product function Torque control with encoder | No |
| Design of the sensor to detect the ambient temperature connectable | 1 motor temperature sensor input, sensors that can be connected: PTC, KTY and Thermo-Click, accuracy±5°C |
| Number of analog inputs | 2 |
| number of digital inputs | 6 |
| Number of digital inputs Note | Optically isolated, free reference potential (own potential group), NPN/PNP-logic selectable via wiring |
| Ambient temperature [°F] during storage maximum [°F] | 158 |
| Design of the interface for bus system Integrated | PROFINET |
| Number of interfaces acc. to Industrial Ethernet | 2 |
| Ambient temperature during storage maximum [°C] | 70 |
| Depth [mm] | 46 |
| Type of analog input Note | Switchable between voltage (-10 to +10 V) and current (0/4 to 20 mA) using a DIP switch |
| Number of analog outputs | 2 |
| Protection function of analog input Overvoltage protection | Yes |
| Ambient temperature [°F] during operation maximum Note | A derating of 3 K/1000 m has to be applied to the Control Units from an installation altitude of 1000 m above sea level |
| Design of the protective insulation | PELV according to EN 50178, safe disconnection from the mains by double/reinforced isolation |
| Operating voltage from external supply voltage maximum [V] | 28.8 |
| Relative humidity maximum Note | RH, condensation not permitted |
| Type of analog output | Non-isolated output |
| Package Quantity | 1 |
