Cpu 6ES72141HG400XB0: Unidad Central de Procesamiento (CPU) 6ES72141HG400XB0.
| Depth | 75 millimetre |
|---|---|
| Width | 110 millimetre |
| Height | 100 millimetre |
| System components present | Yes |
| Power loss, static, current-independent [Pls] | 12 W |
| Number of HW interfaces parallel | 0 |
| Number of HW interfaces, other | 0 |
| Optical interface present | No |
| wall mounting/direct mounting possible | Yes |
| Number of HW interfaces serial RS232 | 0 |
| Design of storage | RAM |
| Number of analog inputs | 2 |
| required storage capacity | 100 kilobyte |
| max. number of relay outputs, integrated | 10 |
| Design | compact |
| Bearing track assembly possible | Yes |
| Number of outputs, digital | 10 |
| Number of HW interfaces serial RS485 | 0 |
| web-server present | Yes |
| Memory expansion | No |
| Number of HW interfaces serial RS422 | 0 |
| max. supply voltage with DC | 28.8 V |
| Display present | No |
| Redundancy-compatible present | No |
| Operating time (1K, binary instruction) | 0 millisecond |
| Number of HW interfaces Industrial Ethernet | 1 |
| Number of HW interfaces serial TTY | 0 |
| min. supply voltage with DC | 20 V |
| Number of HW interfaces PROFINET | 1 |
| Manufacturer product family | S7-1200 |
| Number of inputs, digital | 14 |
| Manufacturer product root | Central processing unit |
| Rack-assembly possible | No |
| Supply voltage type | DC |
| Number of analog outputs | 0 |
| Number of HW interfaces Wireless | 0 |
| description of product type | DC, CPU 1214C DC, Relay |
| Front installation possible | No |
| Package Quantity | 1 |
