DC Power Supply, 176/550V AC; 85/264V AC, 140 W, 5 A, DIN Rail
| Item | DC Power Supply |
|---|---|
| Input Voltage | 176/550V AC; 85/264V AC |
| Output Power - Rated | 140 W |
| Current - Output | 5 A |
| Mounting | DIN Rail |
| Housing Material | Metal |
| Output Voltage | 24V DC |
| Series | SITOP |
| Peak Amps | 15 |
| Status Indicator | LED |
| Hz | 50/60 Hz |
| Depth | 4.76 in |
| Width | 2-3/4 in |
| IP Rating | IP20 |
| Case Material | Metal Case |
| Operating Temp. Range | -25 to 70 deg C |
| Power Rating | 140 W |
| Hold Up Time | 25 msec |
| Style | Switching |
| Standards | BIS, CB-Certificate Yes, CE, CSA, EAC, RCM, REACH Art. 33, RoHS, UL, WEEE (2012/19/EU) |
| Height | 4.92 in |
| Phase - Electrical | Single |
| Output Amps | 5 A |
| Output Noise | 50 mV |
| Connection | Screw |
| Regulated / Unregulated | Regulated |
| Protection | Short-Circuit Proof |
| Current - Peak | 15 A |
| Operating Temperature - Maximum | 158 deg F |
| Input Frequency - Nominal | 50/60 Hz |
| Wire Connection Type | Terminals |
| Special Features | Overvoltage Protection, Short Circuit Protection |
| Operating Temperature - Minimum | -13 deg F |
| Current - Inrush | 35 A |
| Package Quantity | 1 |
