DC to DC Converter, 600V DC to 24V DC, 480VA, 0 Hz, DIN Rail
| Item | DC to DC Converter |
|---|---|
| Converts | 600V DC to 24V DC |
| VA Rating | 480 VA |
| Mounting | DIN Rail |
| Frequency | 0 Hz |
| Phase | Not Applicable |
| Height | 125 mm |
| Width | 90 mm |
| Depth | 125 mm |
| IP Rating | IP20 |
| Status Indicator | LED |
| Operating Temp. Range | -25 to 70 deg C |
| Features | Built-in Incoming Fuse, Parallel Switching for Enhanced Performance, Primary/Secondary Isolation, Product Feature of the Enclosure Housing for Side-by-Side Mounting, Product Function Output Voltage Adjustable, Property of the Output Short-Circuit Proof, Screw-Type Terminals |
| Input Voltage | 600 V DC |
| Output Amps | 20 |
| Connection | Screw |
| Standards | CB-Certificate Yes, CE, CSA, EAC, RCM, REACH Art. 33, RoHS, UL, WEEE (2012/19/EU) |
| Protection | Short-Circuit Proof |
| Output Voltage | 24 V DC |
| Series | SITOP PSU400M |
| Regulated / Unregulated | Regulated |
| Current - Output | 20 A |
| Wire Connection Type | Screw Terminals |
| Power Supply Style | Switching |
| Output Voltage - Maximum | 28.8 V DC |
| Housing Material | Metal |
| Output Voltage - Nominal | 24 V DC |
| Operating Temperature - Maximum | 158 deg F |
| Output Voltage - Minimum | 24 V DC |
| Current - Inrush | 8 A |
| Special Features | Short Circuit Protection |
| Operating Temperature - Minimum | -13 deg F |
| Output Power - Rated | 480 W |
| Package Quantity | 1 |
